20” – 32” Swing CNC Lathes
Center height 10”
- Swing over bed 20”
- Maximum turning length 44.8”
- Swing over cross slide 13.5”
- Swing in the gap 30”
- Headstock spindle taper #7MT
- Headstock spindle bore 3 1/8”
- Width of bed 13”
- Gap width in front of faceplate 9”
- Tailstock quill travel 8”
- Tailstock quill taper #5MT
- Tailstock quill diameter 3”
- Longitudinal rapid feed 200 “/min
- Rapid cross feed 200 “/min––
- Maximum longitudinal travel 60”
Willis 2060CNC
- 3 Gear Headstock w/ Auto Change
- D1-8 Spindle 26–2400RPM’s
- Vertical 8 Station Turret
- Forced headstock lubrication with filter and heat exchanger
- Flood coolant system
- Tailstock
- Low volt controls
- Automatic way lubrication
- High precision ball screws
- Hardened & ground ways w/ Turcite
- Full Enclosure
- Pull Out Chip Pan
- Fanuc 0i-TF control w/ Manual Guide I and AC digital Servo system
- Touchscreen Interface
- X&Z Axis MPG Wheel & Jog Feed w/ Joystick
- Thread Repair Software
- Toolbox and tools w/ operator’s manual
Center height 13”
- Swing over bed 26”
- Maximum longitudinal travel 80”
- Maximum turning length 65”
- Swing over cross slide 18”
- Swing in the gap 37.8”
- Headstock spindle taper #8MT
- Headstock spindle bore 4.13”
- Width of bed 18.9”
- Gap width in front of faceplate 11.8”
- Tailstock quill travel 12”
- Tailstock quill taper #6MT
- Tailstock quill diameter 4.125”
- Longitudinal rapid feed 200 “/min
- Rapid cross feed 200 “/min
Willis 2680CNC
3 Gear Headstock w/ Auto Change
- D1-11 Spindle 26-2000 RPM’s
- Vertical 8 Station Turret
- Forced headstock lubrication with filter and heat exchanger
- Flood coolant system
- Tailstock
- Low volt controls
- Automatic way lubrication
High precision ball screws
- Hardened & ground ways w/ Turcite
- Full Enclosure
- Pull Out Chip Pan or Full Length Conveyor
- Fagor Control and AC digital Servo system
- Touchscreen Interface
- X&Z Axis MPG Wheel & Jog Feed w/ Joystick
- Thread Repair Software
- Toolbox and tools w/ operator’s manual
Center height 13”
- Swing over bed 26”
- Maximum longitudinal travel 120”
- Maximum turning length 104.7”
- Swing over cross slide 18”
- Swing in the gap 37.8”
- Headstock spindle taper #8MT
- Headstock spindle bore 4.13”
- Width of bed 18.9”
- Gap width in front of faceplate 11.8”
- Tailstock quill travel 12”
- Tailstock quill taper #6MT
- Tailstock quill diameter 4.125”
- Longitudinal rapid feed 200 “/min
- Rapid cross feed 200 “/min
Willis 26120CNC
3 Gear Headstock w/ Auto Change
- D1-11 Spindle 26-2000 RPM’s
- Vertical 8 Station Turret
- Forced headstock lubrication with filter and heat exchanger
- Flood coolant system
- Tailstock
- Low volt controls
- Automatic way lubrication
High precision ball screws
- Hardened & ground ways w/ Turcite
- Full Enclosure
- Full Length Conveyor
- Fanuc 0i-TF control w/ Manual Guide I and AC digital Servo system
- Touchscreen Interface
- X&Z Axis MPG Wheel & Jog Feed w/ Joystick
- Thread Repair Software
- Toolbox and tools w/ operator’s manual
Center height 15”
- Swing over bed 30”
- Maximum longitudinal travel 120”
- Maximum turning length 104.7”
- Swing over cross slide 22”
- Swing in the gap 41.7”
- Headstock spindle taper #8MT
- Headstock spindle bore 6”
- Width of bed 18.9”
- Gap width in front of faceplate 11.8”
- Tailstock quill travel 12”
- Tailstock quill taper #6MT
- Tailstock quill diameter 4.125”
- Longitudinal rapid feed 200 “/min
- Rapid cross feed 200 “/min
Willis 30120-6HS CNC
DTT-100-12/VDI40 Turret W/ FANUC Live Turret Servo Motor & C-Axis Hydraulic Spindle Brake
- A2-11 Spindle 26-2000 RPM’s
- Rear chuck adaptor for double chuck
- Forced headstock lubrication with filter and heat exchanger
- Flood coolant system
- Tailstock
- Low volt controls
- Automatic way lubrication
High precision ball screws
- Hardened & ground ways w/ Turcite
- Full Enclosure
- Full Length Conveyor
- Fanuc 0i-TF control w/ Manual Guide I and AC digital Servo system
- Touchscreen Interface
- X&Z Axis MPG Wheel & Jog Feed w/ Joystick
- Thread Repair Software
- Toolbox and tools w/ operator’s manual
Center height 15”
- Swing over bed 30”
- Maximum longitudinal travel 80”
- Maximum turning length 65”
- Swing over cross slide 20”
- Swing in the gap 43”
- Headstock spindle taper #8MT
- Headstock spindle bore 10”
- Width of bed 22”
- Gap width in front of faceplate 11.8”
- Tailstock quill travel 10”
- Tailstock quill taper #6MT
- Tailstock quill diameter 5”
- Longitudinal rapid feed 200 “/min
- Rapid cross feed 200 “/min
Willis 3280-10CNC
3 Gear Headstock w/ Auto Change
- A2-15 Spindle 4-600 RPM’s
- Vertical 8 Station Turret
- Forced headstock lubrication with filter and heat exchanger
- Flood coolant system
- Tailstock
- Low volt controls
- Automatic way lubrication
High precision ball screws
- Hardened & ground ways w/ Turcite
- Full Enclosure
- Single chain type chip conveyor in rear
- Fanuc 0i-TF PLUS w/ Manual Guide I and AC digital Servo system
- Touchscreen Interface
- X&Z Axis MPG Wheel & Jog Feed w/ Joystick
- Thread Repair Software
- Toolbox and tools w/ operator’s manual
